The PCO06 series are mini-precision current transformers. The CT is small size and low cost.
Measuring range:0 - 20 A Measurement Frequency:50 - 60 HzYES
10 Days
24 months
The PCO06 series are mini-precision current transformers. The CT is small size and low cost.
| MODEL | INPUT CURRENT | AVAILABLE OUTPUT |
| PCO06-05 | 5 A | CURRENT OUTPUTS @ 5 mA, 10 mA, 15 mA, 20 mA, VOL TAGE OUTPUTS @ Not available for this model Output can be customized by customer |
| PCO06-10 | 10 A | |
| PCO06-15 | 15 A | |
| PCO06-20 | 20 A |
| Energy and sub-metering products |
| Electrical load monitoring |
| Network equipment |
| Instruments and sensors |
| Control systems |
| Go GREEN initiatives |
| 0.236” window opening (ID) |
| Custom design Turns-Ratio available |
| Approximate weight 10 g |
| Standard Input Current 0 - 20 A |
| Frequency 50 Hz - 60 Hz |
| Standard accuracy 0.1, 0.2, 0.5 |
| Insulation Voltage 4000 Vac / 1 min |
| Operating Temp. - 40 °C to + 65 °C |
| Storage Temp. - 45 °C to + 85 °C |
